SOCIETA' COMMERCIALE YW DKE
 |
| Place of Origin: | China |
| Marca: | FESTO |
| Certificazione: | CE |
| Model Number: | DNC-50-30-PPV-A 1922630 |
| Minimum Order Quantity: | 1 |
|---|---|
| Prezzo: | Negoziabile |
| Packaging Details: | Carton /As The Clients Require |
| Delivery Time: | 1-7Work Days After Payment |
| Payment Terms: | T/T, Western Union,Paypal |
| Supply Ability: | 5000 Pieces/1Month |
| Operation: | Double Acting | Cushioning: | Pneumatic Cushioning |
|---|---|---|---|
| Media: | Compressed Air | Operating pressure: | 0.06 MPa ... 1.2 MPa |
| Ambient temperature: | -20 °C ... 80 °C | Piston-rod end: | Male Thread |
Compact design: saves 11% installation space compared to traditional cylinders, suitable for systems with compact structures.
Profile cylinder: Three sided slotted design for easy integration of proximity sensors (such as magnetic switches), supporting non-contact position detection.
Buffer configuration:
The standard model uses elastic buffering (P-type) at both ends.
Adjustable air buffer (PPV type), suitable for high-speed or high load scenarios, with a buffer length of 20-32 mm.
Piston rod design:
Male thread or special thread (such as square piston rod anti-torsion, extended thread, etc.).
Optional types: double output piston rod, hollow piston rod, with clamping unit (KP type), etc.
| Ambient temperature | -20 °C to 80 °C |
| Media | Compressed Air |
| Piston-rod end | Male Thread |
| Operating pressure | 0.06 MPa to 1.2 MPa |
| Cushioning | Pneumatic Cushioning |
| Operation | Double Acting |
| 163305 | DNC-40-25-PPV-A | 163337 | DNC-50-25-PPV-A | 163369 | DNC-63-25-PPV-A | 163401 |
| 163306 | DNC-40-40-PPV-A | 163338 | DNC-50-40-PPV-A | 163370 | DNC-63-40-PPV-A | 163402 |
| 163307 | DNC-40-50-PPV-A | 163339 | DNC-50-50-PPV-A | 163371 | DNC-63-50-PPV-A | 163403 |
| 163308 | DNC-40-80-PPV-A | 163340 | DNC-50-80-PPV-A | 163372 | DNC-63-80-PPV-A | 163404 |
| 163309 | DNC-40-100-PPV-A | 163341 | DNC-50-100-PPV-A | 163373 | DNC-63-100-PPV-A | 163405 |
| 163310 | DNC-40-125-PPV-A | 163342 | DNC-50-125-PPV-A | 163374 | DNC-63-125-PPV-A | 163406 |
| 163311 | DNC-40-160-PPV-A | 163343 | DNC-50-160-PPV-A | 163375 | DNC-63-160-PPV-A | 163407 |
| 163312 | DNC-40-200-PPV-A | 163344 | DNC-50-200-PPV-A | 163376 | DNC-63-200-PPV-A | 163408 |
| 163313 | DNC-40-250-PPV-A | 163345 | DNC-50-250-PPV-A | 163377 | DNC-63-250-PPV-A | 163409 |
| 163314 | DNC-40-320-PPV-A | 163346 | DNC-50-320-PPV-A | 163378 | DNC-63-320-PPV-A | 163410 |
| 163315 | DNC-40-400-PPV-A | 163347 | DNC-50-400-PPV-A | 163379 | DNC-63-400-PPV-A | 163411 |
| 163316 | DNC-40-500-PPV-A | 163348 | DNC-50-500-PPV-A | 163380 | DNC-63-500-PPV-A | 163412 |
| 163433 | DNC-100-25-PPV-A | 163465 | DNC-125-25-PPV-A | 163497 | ||
| 163434 | DNC-100-40-PPV-A | 163466 | DNC-125-40-PPV-A | 163498 | ||
| 163435 | DNC-100-50-PPV-A | 163467 | DNC-125-50-PPV-A | 163499 | ||
| 163436 | DNC-100-80-PPV-A | 163468 | DNC-125-80-PPV-A | 163500 | ||
| 163437 | DNC-100-100-PPV-A | 163469 | DNC-125-100-PPV-A | 163501 | ||
| 163438 | DNC-100-125-PPV-A | 163470 | DNC-125-125-PPV-A | 163502 | ||
| 163439 | DNC-100-160-PPV-A | 163471 | DNC-125-160-PPV-A | 163503 | ||
| 163440 | DNC-100-200-PPV-A | 163472 | DNC-125-200-PPV-A | 163504 | ||
| 163441 | DNC-100-250-PPV-A | 163473 | DNC-125-250-PPV-A | 163505 | ||
| 163442 | DNC-100-320-PPV-A | 163474 | DNC-125-320-PPV-A | 163506 | ||
| 163443 | DNC-100-400-PPV-A | 163475 | DNC-125-400-PPV-A | 163507 | ||
| 163444 | DNC-100-500-PPV-A | 163476 | DNC-125-500-PPV-A | 163508 |
Application Areas
In the field of general industry, servo drives find application in various types of machinery, including automatic drilling machines, packaging machinery, and material handling systems.
For harsh environments that demand high levels of reliability, servo drives are utilized in settings like steel mills, textile assembly lines, and marine equipment to ensure consistent performance under extreme conditions.
Additionally, servo drives are employed in safety systems that comply with standards such as EN 954-1 and EN 1050. These drives play a crucial role in safety-related control systems, providing a reliable and precise control mechanism for ensuring operator safety.
Our company provides comprehensive product technical support and services for the Piston Pneumatic Cylinder. Our team of experts is dedicated to assisting our customers with any technical inquiries, troubleshooting, and maintenance needs related to the product.
Product Name: Piston Pneumatic Cylinder
Description: The Piston Pneumatic Cylinder is a high-quality, durable cylinder used in various industrial applications.
Packaging: The Piston Pneumatic Cylinder is carefully packaged in a sturdy cardboard box to ensure safe delivery.
Shipping: We offer fast and reliable shipping options for the Piston Pneumatic Cylinder to ensure timely delivery to our customers.
