Product Description:
The F72G series filters are thoughtfully designed and boast several remarkable features:
Modular Design: Being a part of the Excelon modular system allows for easy installation alongside other Excelon products like pressure regulators and oil misters, making assembly and maintenance a breeze.
Efficient Filtration Capacity: Utilizing sintered polypropylene filter cartridges, these filters can effectively eliminate moisture and particulate contaminants from compressed air. They offer various filtering accuracies, including options like 5 μm, 25 μm, 40 μm, and 75 μm.
Various Drainage Methods: Depending on the model, manual (such as 1/4 turn knob), semi-automatic, or automatic drainage options are available.
Flexible Selection of Filter Cups: Users have the choice between transparent polycarbonate filter cups (featuring a liquid level indicator for easy water accumulation monitoring) and metal filter cups (typically zinc alloy or aluminum). Transparent cups handle a working pressure of around 10 bar, while metal cups can withstand pressures up to 17 bar.
Wide Working Temperature Range: The working environment temperature range varies based on the type of filter cup being used.
- Transparent Cup with Protective Cover: approximately -20 °C to +50 °C
- Metal Cup: -20 °C to +65 °C (F72G) or even -20 °C to +80 °C (F73G/F74G)
Optional Filter Life Indicator: This handy feature offers mechanical (visual indication with a color change from green to red indicating the need for filter replacement) or electrical options, enabling users to stay informed about the filter's status for timely preventive maintenance.
Durable Material Construction:
- F72G Model: The shell is typically zinc alloy, the transparent cup is polycarbonate, the metal cup is zinc alloy, and the sealing elastomer is predominantly nitrile rubber or chloroprene rubber.
- F73G/F74G Models: The housing is usually aluminum alloy.
Applications:
The F72G series filters are widely used in many industrial fields that require compressed air quality due to their reliable performance.
In rail transit, these filters are utilized for pneumatic circuits such as train braking systems and door controls to ensure clean air sources and reliable system operation.
For marine engines, the filters are essential in the marine environment to process compressed air for starting and control systems, eliminating potential moisture and impurities.
In industrial automation, the F72G series filters are widely applied in pneumatic equipment found in various industries including petroleum, chemical, power, textile, coal, packaging, medical, automotive, metallurgy, food and beverage. They serve to protect precision pneumatic components from pollution and wear.
Furthermore, in the general manufacturing industry, these filters play a crucial role in providing clean air sources for a variety of pneumatic tools and equipment on the production line. This helps to extend the equipment's service life and reduce downtime caused by malfunctions.
