SMC Pneumatic Speed Regulating Throttle Valve AS1201F-M5-06

Product Description:

Enhanced Visibility and Scale: Many models feature a scale window for numerical flow management, with some including a vernier for precise 1/4-scale settings. The scale is visible from 360 degrees, improving accessibility for inspection and maintenance.

Ergonomic and Efficient Operation: The push-to-lock mechanism enhances needle valve locking operation, making setup faster and reducing setup time and potential errors. Some models also have a larger knob diameter (approximately twice as large) for easier adjustment.

Space-Saving and Lightweight Design: The compact design saves space, and some models achieve weight reduction of about 27%.

Easy Installation and Connection: Tube insertion and removal are facilitated with reduced insertion force (by up to 30%) and withdrawal force (by up to 20%) while maintaining pull-out strength. The 360° free orientation piping capability (in elbow/universal types) allows for flexible installation.

Durability and Specialized Specifications: Constructed with metal bodies (e.g., zinc alloy) or specific materials for standard use, with some offering stainless steel for corrosion resistance. Non-electrolytic nickel plating is standardized for some components. Options include cleanroom (low-dust generation) and corrosion-resistant models.

Integrated Functions: Certain variants combine a speed control valve with other functions, such as a residual pressure release valve (for one-button exhaust) or a pilot-operated check valve (for cylinder speed control and temporary intermediate stopping).

Applications:

SMC's AS series speed control valves are primarily utilized to manage the speed of pneumatic actuators by controlling the flow of compressed air.

Low-Speed Control: Specifically engineered for low-speed control tasks, such as achieving cylinder movement speeds in the range of 1 mm/s to 50 mm/s, or 50 mm/s to 150 mm/s.

General Speed Regulation in Pneumatic Systems: These valves are employed for meter-out flow control, typically involving exhaust port throttling in one direction, alongside allowing unrestricted flow in the opposite direction through a built-in check valve, facilitating easy and consistent speed adjustments.

Applications Requiring Compact and Efficient Components: The compact and lightweight design of these valves makes them ideal for machinery and systems where space utilization is crucial, ensuring efficient use of available space.

Specialized Environments: Specific variants are designed for utilization in cleanrooms to minimize dust generation and in environments necessitating resistance to corrosion.

I trust that this translation and summary aid in your comprehension of the capabilities of the SMC AS series speed control valves. Should you need more detailed information on a specific model or application, please do not hesitate to reach out.

Support and Services:

Our product technical support team for Pneumatic Pipe Fittings is dedicated to helping you with any issues you may encounter. We offer expert assistance in troubleshooting, installation guidance, and product usage to ensure optimal performance.

In addition to technical support, we provide a range of services for our Pneumatic Pipe Fittings, including maintenance and repair options. Our team is committed to ensuring that your pneumatic systems operate efficiently and reliably.

Packing and Shipping:

Product Name: Pneumatic Pipe Fittings

Description: High-quality pneumatic pipe fittings for industrial applications.

Product Packaging:

- The pneumatic pipe fittings are securely packed in a sturdy cardboard box to prevent any damage during transportation.

- Each fitting is individually wrapped in bubble wrap to provide additional protection.

- The packaging includes a list of contents and installation instructions for easy reference.

Shipping Information:

- Orders are typically processed within 1-2 business days.

- We offer standard and expedited shipping options to meet your delivery needs.

- Our shipping partners ensure safe and timely delivery of your pneumatic pipe fittings.
